Features
EDGE-TO-EDGE COOKTOP
Continuous, edge-to-edge cooktop give you a large cooking space and can handle any cookware
CENTER OVAL BURNER
Large oval fifth burner is ideal for griddle or odd-size cookware.
PRECISE SIMMER BURNER
This burner setting provides low, even heat so delicate dishes don't burn.
SELF-CLEAN OVEN
A GE invention, the Self-Clean feature uses concentrated heat to remove baked-on splatters, eliminating the need for scrubbing or use of harsh chemicals.
18,000 BTU POWER BOIL BURNER
Boil water fast with intense heat from this 18,000 BTU burner.
Additional Features
HEAVY DUTY, DISHWASHER SAFE GRATES
Easily and safely clean grates in the dishwasher or place in the bottom of the self-clean oven
REMOVABLE FULL-WIDTH STORAGE DRAWER
Store cookware or kitchen accessories
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
White
Manufacturer Color
White
Cooktop
Burners/Elements
5
Burners/Elements Output
• Burner - Left Front: 18,000 BTU Power Boil
• Burner - Left Rear: 5,000 BTU Precise Simmer
• Burner - Right Front: 9,500 BTU
• Burner - Right Rear: 12,000 BTU
• Burner - Center: 10,000 BTU Oval
• Burner - Left Rear: 5,000 BTU Precise Simmer
• Burner - Right Front: 9,500 BTU
• Burner - Right Rear: 12,000 BTU
• Burner - Center: 10,000 BTU Oval
Burners
Sealed
Oven
Capacity (cu. ft.)
5.0 cu. ft.
Number of Ovens
Single
Features
Control Lock
Yes
Convection
No
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Bake: 16000 BTU / Broil: 13.500 BTU
• Ignition system: Electronic
• Edge-to-edge continuous heavy cast iron grates
• One-Piece upswept porcelain-enamel cooktop
• Digital temperature display
• Electronic touch oven controls
• Audible preheat signal
• Interior oven light: 1 Incandescent
• Oven rack features: 2 Oven racks
• Ignition system: Electronic
• Edge-to-edge continuous heavy cast iron grates
• One-Piece upswept porcelain-enamel cooktop
• Digital temperature display
• Electronic touch oven controls
• Audible preheat signal
• Interior oven light: 1 Incandescent
• Oven rack features: 2 Oven racks
Drawer Features
Storage
Yes
Electrical Information
Information
• 120V
• 60Hz
• 15A
• 60Hz
• 15A
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• Griddle
• LP conversion kit
• LP conversion kit
Optional
Grates: JXGRATE1
Dimensions
Class Width
30"
Width
30 inch(es) / 76.20 cm
Height
47.25 inch(es) / 120.02 cm
Depth (Without Handles)
26.25 inch(es) / 66.68 cm
Depth (Including Handles)
28.75 inch(es) / 73.02 cm
Weight
189.99 lb(s) / 86.18 kg
Additional Dimensions
• Oven interior dimensions (W x H x D): 24" x 19" x 19"
• Height to cooking surface: 36 - 36 1/2"
• Depth with door open: 46.25"
• Height to cooking surface: 36 - 36 1/2"
• Depth with door open: 46.25"
Shipping Dimensions
Width
32.9 inch(es) / 83.57 cm
Height
49.6 inch(es) / 125.98 cm
Depth
30.8 inch(es) / 78.23 cm
Weight
209.99 lb(s) / 95.25 kg
Warranty
Warranty
1-Year on parts and labor
UPC
UPC#
084691849650
