Features
ADA COMPLIANT
Designed to be accessible and easy to open.
LED LIGHTING
Find exactly what you’ve been looking for under crisp, clear lighting.
Additional Features
EQUIPPED FOR OPTIONAL ICEMAKER
Easily accommodates the installation of an icemaker.
UPFRONT ELECTRONIC TEMPERATURE CONTROLS
Controls are located in an easy-to-reach position
Specifications
General
Refrigerator Type
Top Freezer
Installation Type
Freestanding
Door Hinge
Right
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Capacity
Total
11.6 cu. ft.
Refrigerator
8.45 cu. ft.
Freezer
3.15 cu. ft.
Refrigerator Features
Technologies
Never Clean condenser
Frost Free
Yes
Interior Light
Yes
Crisper Drawers
Yes
Gallon Door
Yes
Additional Information
• 2 cabinet drawers
• 2 full-width adjustable cabinet shelves
• 3 full-width fixed door shelves
• Reversible hinges
• Rounded doors
• Color-matched recessed
• Easily removable door gaskets
• 2 full-width adjustable cabinet shelves
• 3 full-width fixed door shelves
• Reversible hinges
• Rounded doors
• Color-matched recessed
• Easily removable door gaskets
Freezer Features
Additional Freezer Information
• 1 Ice Tray
• Spillproof freezer floor
• 2 full-width fixed door shelves
• 1 full-width wire cabinet shelf
• Spillproof freezer floor
• 2 full-width fixed door shelves
• 1 full-width wire cabinet shelf
Ice and Water
Ice System
None
Water System
None
Electrical Information
Information
• 120 V
• 15 A
• 60 Hz
• 15 A
• 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Accessories
Optional
Icemaker: IM4D
Dimensions
Class Width
23" to 28.9"
Class Height
55" - 60"
Width
24 inch(es) / 60.96 cm
Height (With Hinge)
59.87 inch(es) / 152.08 cm
Depth (Without Handles)
28.63 inch(es) / 72.71 cm
Depth (With Handles)
28.63 inch(es) / 72.71 cm
Weight
137 lb(s) / 62.14 kg
Additional Dimensions
• Case depth without door: 25 5/8 in
• Depth with door open 90°: 50 5/8 in
• Height to top of case: 59 3/8 in
• Height to top of hinge: 59 7/8 in
• Width with door open 90° incl. handle: 25 1/8 in
• Back air clearances: 3 in
• Side air clearances: 1 in
• Top air clearances: 4 in
• Depth with door open 90°: 50 5/8 in
• Height to top of case: 59 3/8 in
• Height to top of hinge: 59 7/8 in
• Width with door open 90° incl. handle: 25 1/8 in
• Back air clearances: 3 in
• Side air clearances: 1 in
• Top air clearances: 4 in
Shipping Dimensions
Width
26.1 inch(es) / 66.29 cm
Height
63 inch(es) / 160.02 cm
Depth
30.7 inch(es) / 77.98 cm
Weight
150.99 lb(s) / 68.49 kg
Warranty
Warranty
Limited one-year warranty parts and labor
UPC
UPC#
084691818106
