Features
SELF-CLEAN OVEN
A GE invention, the Self-Clean feature uses concentrated heat to remove baked-on splatters, eliminating the need for scrubbing or use of harsh chemicals.
SENSI-TEMP TECHNOLOGY
Enjoy the same cooking power as a traditional coil.
Additional Features
CHROME DRIP BOWLS
Contain spills and remove for easy cleaning
ELECTRONIC CLOCK AND TIMER
Features a convenient digital clock and easy-to-use time with an audible signal to help coordinate cooking times in the kitchen.
Specifications
General
Fuel Type
Electric
Installation Type
Drop-in
Color
Black
Manufacturer Color
Black
Cooktop
Burners/Elements
4
Burners/Elements Output
• Element - Left Front: 2400W 5-turn
• Element - Left Rear: 1250W 4-turn
• Element - Right Front: 1250W 4-turn
• Element - Right Rear: 1250W 4-turn
• Element - Left Rear: 1250W 4-turn
• Element - Right Front: 1250W 4-turn
• Element - Right Rear: 1250W 4-turn
Burner/Element Size
• Element - Left Front: 8"
• Element - Left Rear: 6"
• Element - Right Front: 6"
• Element - Right Rear: 6"
• Element - Left Rear: 6"
• Element - Right Front: 6"
• Element - Right Rear: 6"
Elements
Coil
Oven
Capacity (cu. ft.)
3.0 cu. ft.
Number of Ovens
Single
Features
Technologies
Sensi-temp technology
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Made in America: 70 to 90% U.S. Content
• Chrome drip bowls
• Electronic clock and timer
• Oven Door Features: Big View Oven Window, Glass Door
• Handle Design: D-shaped
• Cooktop Surface:Lift-Up Overhanging Cooktop Porcelain Enamel
• Oven Control Features: Audible Preheat Signal, Auto Oven Shut-Off, Electronic Clock and Timer
• Self-Clean Oven Door Lock: Automatic
• Heating Element "ON" Indicator Light
• Oven Feature: 4-Pass Bake Element, 4-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 4 Rack Positions
• Oven Interior: Gray
• Chrome drip bowls
• Electronic clock and timer
• Oven Door Features: Big View Oven Window, Glass Door
• Handle Design: D-shaped
• Cooktop Surface:Lift-Up Overhanging Cooktop Porcelain Enamel
• Oven Control Features: Audible Preheat Signal, Auto Oven Shut-Off, Electronic Clock and Timer
• Self-Clean Oven Door Lock: Automatic
• Heating Element "ON" Indicator Light
• Oven Feature: 4-Pass Bake Element, 4-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 4 Rack Positions
• Oven Interior: Gray
Electrical Information
Information
• Amp Rating at 208V: 40
• Amp Rating at 240V: 40
• Bake Wattage: 2000W
• Broiler Wattage: 3400W
• KW Rating at 208V: 8.0
• KW Rating at 240V: 10.6
• Amp Rating at 240V: 40
• Bake Wattage: 2000W
• Broiler Wattage: 3400W
• KW Rating at 208V: 8.0
• KW Rating at 240V: 10.6
Certifications and Approvals
ADA Compliant
Yes
Dimensions
Class Width
27"
Width
27.13 inch(es) / 68.90 cm
Height
28.44 inch(es) / 72.23 cm
Depth (Without Handles)
24.19 inch(es) / 61.44 cm
Depth (Including Handles)
27.19 inch(es) / 69.06 cm
Weight
103.99 lb(s) / 47.17 kg
Additional Dimensions
• Cooktop Width: 27.125 in
• Cabinet Opening: 27.0 in
• Cabinet Width: 27.0 in
• Oven Interior Dimensions (W x H x D) (in.): 19 x 15 x 18
• Depth with Door Open: 44.1875 in
• Cabinet Opening: 27.0 in
• Cabinet Width: 27.0 in
• Oven Interior Dimensions (W x H x D) (in.): 19 x 15 x 18
• Depth with Door Open: 44.1875 in
Shipping Dimensions
Width
31 inch(es) / 78.74 cm
Height
33 inch(es) / 83.82 cm
Depth
30 inch(es) / 76.20 cm
Weight
124.01 lb(s) / 56.25 kg
Warranty
Warranty
• Parts Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
UPC
UPC#
084691909392
