Features
LED LIGHTING
Find exactly what you’ve been looking for under crisp, clear lighting.
UPFRONT TEMPERATURE CONTROLS
Easy-to-use controls regulate both fresh food and freezer sections
ADA COMPLIANT
Designed to be accessible and easy to open.
Specifications
General
Refrigerator Type
Top Freezer
Installation Type
Freestanding
Door Hinge
Right
Color
White
Manufacturer Color
White
Capacity
Total
16.6 cu. ft.
Refrigerator
12.6 cu. ft.
Freezer
4.03 cu. ft.
Refrigerator Features
Digital Display
No
Frost Free
Yes
Interior Light
Yes
Crisper Drawers
Yes
Deli Drawer/Meat
Yes
Gallon Door
Yes
Additional Information
• Air tower temperature management features
• Upfront temperature controls
• Reversible hinges
• 1 Glass drawer cover
• 2 Full-width adjustable wire shelves
• 2 Full-width door shelves with gallon storage
• Dairy compartment
• 2-Point front adjustable leveling system
• Easily removable door gaskets
• Never clean condenser
• Door stops
• Coil-free back
• Upfront temperature controls
• Reversible hinges
• 1 Glass drawer cover
• 2 Full-width adjustable wire shelves
• 2 Full-width door shelves with gallon storage
• Dairy compartment
• 2-Point front adjustable leveling system
• Easily removable door gaskets
• Never clean condenser
• Door stops
• Coil-free back
Freezer Features
Additional Freezer Information
• Icemaker ready
• 1 Adjustable wire shelf
• 2 Full-width fixed door shelves
• Spillproof freezer floor
• 1 Adjustable wire shelf
• 2 Full-width fixed door shelves
• Spillproof freezer floor
Electrical Information
Information
• 120V
• 60Hz
• 15A
• 60Hz
• 15A
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Accessories
Optional
Icemaker kit: IM4D, IM4LED
Dimensions
Class Width
23" to 28.9"
Class Height
60" - 65"
Width
28 inch(es) / 71.12 cm
Height (With Hinge)
64.75 inch(es) / 164.46 cm
Depth (Without Handles)
30.5 inch(es) / 77.47 cm
Depth (With Handles)
30.5 inch(es) / 77.47 cm
Weight
152.01 lb(s) / 68.95 kg
Additional Dimensions
• Case depth without door: 26 3/4"
• Depth with door open 90°: 57"
• Height to top of case: 64 1/4"
• Width with door open 90 degrees less handle: 28 1/2"
• Back air clearances: 1"
• Side air clearances: 0 3/4"
• Top air clearances: 1"
• Depth with door open 90°: 57"
• Height to top of case: 64 1/4"
• Width with door open 90 degrees less handle: 28 1/2"
• Back air clearances: 1"
• Side air clearances: 0 3/4"
• Top air clearances: 1"
Shipping Dimensions
Width
31.3 inch(es) / 79.50 cm
Height
67.3 inch(es) / 170.94 cm
Depth
35.5 inch(es) / 90.17 cm
Weight
170.99 lb(s) / 77.56 kg
Warranty
Warranty
Limited 1-year entire appliance on parts and labor
UPC
UPC#
084691847496
